DuPont AmberLite IRA402 Cl Ion Exchange Resin 1.07 g/mL for Demineralization
Dettagli:
| Luogo di origine: | Cina |
| Marca: | Dupont |
| Certificazione: | ISO9001 |
| Numero di modello: | DuPont ™ Amberlite ™ IRA402 CL |
| Documento: | IER-AmberLite-IRA402-Cl-PDS...en.pdf |
Termini di pagamento e spedizione:
| Quantità di ordine minimo: | 1pc |
|---|---|
| Prezzo: | negoziabile |
| Imballaggi particolari: | imballaggio di esportazione standard |
| Tempi di consegna: | 5-8 giorni di lavoro |
| Termini di pagamento: | T/t |
| Capacità di alimentazione: | 60000 unità al mese |
|
Informazioni dettagliate |
|||
| Perle non graffiate: | ≥ 90% | Gonfiore (cl⁻ → oh⁻): | ≤ 20% |
|---|---|---|---|
| Densità di particelle: | 1,07 g/ml | questo modello applicazioni primarie: | Applicazioni di demineralizzazione industriale |
| Intervallo di temperatura: | Forma OH⁻: 5 - 60 ° C (41 - 140 ° F) † | Forma cl⁻: | 5 - 100 ° C (41 - 212 ° F) |
| ciclo di servizio: | 1-14 | Stabile: | 0--14 |
| Evidenziare: | DuPont AmberLite IRA402 resin,ion exchange resin for demineralization,water treatment resin with warranty |
||
Descrizione di prodotto
DuPont™ AmberLite™ IRA402 Cl Ion Exchange Resin For Industrial Demineralization Applications
DuPont™ AmberLite™ IRA402 Cl is a gaussian, gel-type, strong base anion exchange resin (Type I) designed for industrial demineralization applications. With a long-established track record of reliable performance, this resin offers an excellent balance of high capacity, mechanical strength, and silica selectivity.
Applications
- Demineralization
- Ideal for treating water with a high percentage of silica
- Effective for removing strong and weak acids and achieving low silica leakage
Compatible System Designs
- Co-current regeneration systems
Typical Properties
Physical Properties
| Property | Specification |
|---|---|
| Copolymer | Styrene-divinylbenzene |
| Matrix | Gel |
| Type | Strong base anion, Type I |
| Functional Group | Trimethylammonium |
| Physical Form | Amber translucent spherical beads |
Chemical Properties
| Property | Specification |
|---|---|
| Ionic Form (as shipped) | Cl⁻ |
| Total Exchange Capacity | ≥ 1.20 eq/L (Cl⁻ form) |
| Water Retention Capacity | 49.0 - 59.0% (Cl⁻ form) |
Particle Size Distribution
| Parameter | Specification |
|---|---|
| Uniformity Coefficient | ≤ 1.80 |
| < 300 μm | ≤ 1.0% |
| > 1180 μm | ≤ 5.0% |
For additional particle size information, refer to Document No. 45-D00954-en.
Stability
- Whole Uncracked Beads: ≥ 90%
- Swelling (Cl⁻ → OH⁻): ≤ 20%
Density
- Particle Density: 1.07 g/mL
- Shipping Weight: 670 g/L
Operating Conditions
- Temperature Range:
- OH⁻ form: 5 - 60°C (41 - 140°F) †
- Cl⁻ form: 5 - 100°C (41 - 212°F)
- pH Range:
- Service Cycle: 1 - 14
- Stable: 0 - 14
† Operating at elevated temperatures (e.g., >60-70°C) may impact resin life. Consult DuPont technical representatives for details.
Hydraulic Characteristics
- Backwash Expansion: Estimated bed expansion as a function of backwash flow rate and temperature is shown in Figure 1.
- Pressure Drop: Estimated pressure drop as a function of service flow rate and temperature is shown in Figure 2 (valid for clean water and well-classified beds at service run start).
(Note: Refer to original document for graphical data.)
Safety & Compliance
Warning: Strong oxidizing agents (e.g., nitric acid) may degrade the resin or cause violent reactions. Consult experts before use.
Users should review safety data sheets (SDS) and ensure compliance with local regulations.
