DuPont™ AmberLite™ HPR4200 CL High-quality Resin For Industrial Demineralization applications
Dettagli:
| Luogo di origine: | Cina |
| Marca: | Dupont |
| Certificazione: | ISO9001 |
| Numero di modello: | DuPont ™ Amberlite ™ HPR4200 CL |
| Documento: | IER-AmberLite-HPR4200-Cl-PD...en.pdf |
Termini di pagamento e spedizione:
| Quantità di ordine minimo: | 1pc |
|---|---|
| Prezzo: | negoziabile |
| Imballaggi particolari: | imballaggio di esportazione standard |
| Tempi di consegna: | 5-8 giorni di lavoro |
| Termini di pagamento: | T/t |
| Capacità di alimentazione: | 60000 unità al mese |
|
Informazioni dettagliate |
|||
| Applicazioni principali: | Applicazioni di demineralizzazione industriale | Perle non graffiate: | ≥ 90% |
|---|---|---|---|
| Gonfiore (cl⁻ → oh⁻): | 20% | Densità di particelle: | 1,07 g/ml |
| Avvertimento: | Forti agenti ossidanti (ad es. Acido nitrico) possono degradare la resina o causare reazioni violent | Forma fisica: | Perle sferiche traslucide gialle |
| Tipo: | Forte anione base, tipo I | ||
Descrizione di prodotto
1. Product Overview
DuPont™ AmberLite™ HPR4200 Cl is a uniform particle size, gel-type, strong base anion exchange resin (Type I) designed for industrial demineralization applications requiring high performance and cost-effective operation. Its balanced chemical properties and particle size provide excellent operating capacity with low pressure drop while reducing chemical regenerant and rinse water consumption. Compatible with all system technologies, it can be used in lead single or layered anion beds and mixed bed polishers, allowing users to inventory only one strong base anion resin for various demineralization needs. The light color of this resin enables easy visual distinction from dark-colored cation resins after backwash separation.
2. Applications
-
Demineralization
-
Ideal for treating water with a high percentage of silica
-
Effective for removing strong and weak acids and achieving low silica leakage
-
-
Mixed bed polishing
3. Compatible System Designs
-
Mixed beds
-
Packed beds
-
Layered beds
-
Counter-current / hold-down systems
-
Co-current systems
4. Recommended Resin Pairings
-
For mixed beds:
-
AmberLite™ HPR1200 H (gel)
-
AmberLite™ HPR1300 H (gel)
-
-
For layered beds:
-
AmberLite™ HPR9500 (macroporous)
-
AmberLite™ HPR9600 (macroporous)
-
5. Historical Reference
Previously sold as DOWEX MARATHON™ 4200 Cl Ion Exchange Resin.
6. Typical Properties
Physical Properties
| Property | Specification |
|---|---|
| Copolymer | Styrene-divinylbenzene |
| Matrix | Gel |
| Type | Strong base anion, Type I |
| Functional Group | Trimethylammonium |
| Physical Form | Yellow translucent spherical beads |
Chemical Properties
| Property | Specification |
|---|---|
| Ionic Form (as shipped) | Cl⁻ |
| Total Exchange Capacity | ≥ 1.30 eq/L (Cl⁻ form) |
| Water Retention Capacity | 49.0 – 55.0% (Cl⁻ form) |
Particle Size Distribution
| Parameter | Specification |
|---|---|
| Particle Diameter | 650 ± 50 μm |
| Uniformity Coefficient | ≤ 1.25 |
| < 300 μm | ≤ 0.3% |
| > 850 μm | ≤ 5.0% |
ℹ For additional particle size information, refer to Document No. 45-D00954-en.
Stability
-
Whole Uncracked Beads: ≥ 90%
-
Swelling (Cl⁻ → OH⁻): 20%
Density
-
Particle Density: 1.07 g/mL
-
Shipping Weight: 670 g/L
7. Operating Conditions
-
Temperature Range:
-
OH⁻ form: 5 – 60°C (41 – 140°F) †
-
Cl⁻ form: 5 – 100°C (41 – 212°F)
-
-
pH Range:
-
Service Cycle: 1 – 14
-
Stable: 0 – 14
-
† Operating at elevated temperatures (e.g., >60–70°C) may impact resin life. Consult DuPont technical representatives for details.
8. Hydraulic Characteristics
-
Backwash Expansion: Estimated bed expansion as a function of backwash flow rate and temperature is shown in Figure 1.
-
Pressure Drop: Estimated pressure drop as a function of service flow rate and temperature is shown in Figure 2 (valid for clean water at service run start).
(Note: Refer to original document for graphical data.)
9. Safety & Compliance
-
Warning: Strong oxidizing agents (e.g., nitric acid) may degrade the resin or cause violent reactions. Consult experts before use.
-
Users should review safety data sheets (SDS) and ensure compliance with local regulations.
