DuPont AmberLite HPR650 H Cation Exchange Resin with Sulfonic Acid Functional Groups and Styrene-Divinylbenzene Matrix for Mixed Bed Applications
Dettagli:
| Luogo di origine: | Cina |
| Marca: | Dupont |
| Certificazione: | ISO9001 |
| Numero di modello: | DuPont ™ Amberlite ™ HPR650 H |
| Documento: | IER-AmberLite-HPR650-H-PDS-...en.pdf |
Termini di pagamento e spedizione:
| Quantità di ordine minimo: | 1pc |
|---|---|
| Prezzo: | negoziabile |
| Imballaggi particolari: | imballaggio di esportazione standard |
| Tempi di consegna: | 5-8 giorni di lavoro |
| Termini di pagamento: | T/t |
| Capacità di alimentazione: | 60000 unità al mese |
|
Informazioni dettagliate |
|||
| Copolimero HPR650 H: | Stirene-divinilbenzene | Matrice HPR650 H: | Gel |
|---|---|---|---|
| HPR650 Tipo H: | Forte catione acido | Gruppo Funzionale HPR650 H: | Acido solfonico |
| Capacità di ritenzione idrica HPR650 H: | 46,0 - 52,0% (modulo H⁺) | Conversione ionica HPR650 H: | H⁺ ≥ 99% |
| Applicazione HPR650 H: | Applicazioni di demineralizzazione del letto misto per l'industria dell'energia | ||
| Evidenziare: | HPR650 H Cation Exchange Resin,Sulfonic Acid Functional Groups Ion Exchange Resin,Styrene-Divinylbenzene Matrix AmberLite HPR650 H |
||
Descrizione di prodotto
Designed for use in mixed-bed applications for condensate polishing in both nuclear (PWR) and fossil power plants, as well as for industrial water demineralization.
AmberLite™ HPR650 H is a high-quality, high-capacity cation exchange resin. It is a strong acid cation exchange gel resin with sulfonic acid functional groups and a styrene-divinylbenzene matrix.
This resin is known for its uniform particle size, excellent mechanical strength, and oxidative stability, making it ideal for high-flowrate applications. Formerly marketed as Dowex Monosphere 650C, it complies with FDA regulation 21 CFR 173.25 for use as a food additive.
- Recommended Pairings:
- AmberLite™ HPR550 OH Ion Exchange Resin (gel)
- AmberLite™ HPR9000 OH Ion Exchange Resin (macroporous)
- Additional Options:
- AmberLite™ HPR550 Cl Ion Exchange Resin (gel)
- AmberLite™ HPR9000 SO₄ Ion Exchange Resin (macroporous)
- Mixed bed condensate polishing in PWR nuclear power plants
- Mixed bed condensate polishing in fossil fuel power plants
- Mixed bed polishing in industrial demineralization systems
AmberLite™ HPR650 H Ion Exchange Resin was previously sold as DOWEX MONOSPHERE™ 650C (H) Ion Exchange Resin.
| Physical Properties | |
|---|---|
| Copolymer | Styrene-divinylbenzene |
| Matrix | Gel |
| Type | Strong acid cation |
| Functional Group | Sulfonic acid |
| Physical Form | Dark amber, translucent, spherical beads |
| Chemical Properties | |
|---|---|
| Ionic Form as Shipped | H⁺ |
| Total Exchange Capacity | ≥ 2.0 eq/L (H⁺ form) |
| Water Retention Capacity | 46.0 - 52.0% (H⁺ form) |
| Ionic Conversion | H⁺ ≥ 99% |
| Particle Size | |
|---|---|
| Particle Diameter | 650 ± 50 μm |
| Uniformity Coefficient | ≤ 1.10 |
| < 300 μm | ≤ 0.5% |
| > 850 μm | ≤ 5.0% |
| Purity (dry basis) | |
|---|---|
| Metals: |
|
| Stability | |
|---|---|
| Whole Uncracked Beads | ≥ 95% |
| Friability: |
|
| Swelling (Na⁺ -> H⁺) | 7% |
| Density | |
|---|---|
| Particle Density | 1.22 g/mL |
| Shipping Weight | 785 g/L |
For additional particle size information, please refer to the Particle Size Distribution Cross Reference Chart (Form No. 45-D00954-en).
Temperature Range (H⁺ form): 5 - 150°C (41 - 302°F)
pH Range (Stable): 0 - 14
For further details regarding recommended minimum bed depth, operating conditions, and regeneration procedures for mixed beds (Form No. 45-D01127-en) or separate beds (Form No. 45-D01131-en) in water treatment, please refer to our Technical Facts documents.
