DuPont XP 51 IG Hollow Fiber Membrane for Wastewater Treatment
Dettagli:
| Place of Origin: | China |
| Marca: | Dupont |
| Certificazione: | CE |
| Model Number: | IntegraTec™ XP 51 IG(previously SFP-2860XP) |
Termini di pagamento e spedizione:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Prezzo: | negoziabile |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Supply Ability: | 60000 Units per Month |
|
Informazioni dettagliate |
|||
| The Brand of this model: | Dupont™ | Model: | XP 51 IG |
|---|---|---|---|
| XP 51 IG Filtration: | Out-In Pressurized | Membrane Type of XP 51 IG: | Hollow fiber |
| Membrane Material of XP 51 IG: | PVDF (Polyvinylidene Fluoride | Membrane Pore Size: | Approx. 0.03 µm |
| Module Operating Process: | Dead-end | Other Wetted Module Components: | Polyurethane, polyethylene, and polyamide |
| Active Membrane Area: | 51 m² | Shipping Weight of this model: | 60 kg |
| Weight Empty: | 48 kg | Weight Filled: | 83 kg |
| Application of the product: | Wastewater treatment | Advantages: | • Municipal drinking water. • Industrial utility water. • Industrial wastewater reuse. • Municipal wastewater filtration. • RO pretreatment |
| Evidenziare: | DuPont XP 51 hollow fiber membrane,wastewater treatment UF membrane,DOW UF membrane with warranty |
||
Descrizione di prodotto
DuPont IntegraTec XP 51 IG Membrane for NaOH/Cl2 Production
Product Specifications
| Attribute | Value |
|---|---|
| Brand | Dupont™ |
| Model | XP 51 IG |
| Filtration Type | Out-In Pressurized |
| Membrane Type | Hollow fiber |
| Membrane Material | PVDF (Polyvinylidene Fluoride) |
| Membrane Pore Size | Approx. 0.03 µm |
| Module Operating Process | Dead-end |
| Other Wetted Components | Polyurethane, polyethylene, and polyamide |
| Active Membrane Area | 51 m² |
| Shipping Weight | 60 kg |
| Weight Empty | 48 kg |
| Weight Filled | 83 kg |
| Primary Application | Wastewater treatment |
Key Advantages
- Municipal drinking water treatment
- Industrial utility water processing
- Industrial wastewater reuse
- Municipal wastewater filtration
- RO pretreatment solutions
Product Description
The DuPont IntegraTec XP 51 IG is an advanced ion exchange membrane engineered for high-efficiency chlor-alkali electrolysis, delivering superior performance in caustic soda (NaOH), chlorine (Cl₂), and hydrogen (H₂) production.
Designed with DuPont's proprietary IntegraTec technology, this membrane ensures exceptional current efficiency (≥96%) and low energy consumption, optimizing operational costs in membrane cell electrolyzers. Its reinforced perfluorinated polymer structure provides outstanding resistance to harsh chemical environments, including concentrated brine and high-temperature conditions.
The XP 51 IG features low gas permeability and stable voltage drop, ensuring consistent output and extended service life (typically >5 years). Ideal for modern electrolysis plants, it supports sustainable production with reduced power requirements and minimized caustic impurities.
Why Choose the XP 51 IG?
Smarter Filtration, Unmatched Purity
Proprietary pore structure technology ensures superior removal of pathogens, microplastics, and colloidal particles while preserving vital minerals for safer, cleaner water outcomes.
Ultra-High Efficiency
Engineered with DuPont's cutting-edge hydrophilic polymers, the XP 51 IG achieves up to 20% higher flux rates compared to conventional membranes, translating to faster processing and energy savings.
Built for Tough Conditions
Exceptional resistance to chlorine, pH extremes, and organic fouling ensures reliable operation in industrial wastewater, brackish water, or high-turbidity applications.
Sustainable by Design
Reduced fouling tendencies and easy-to-clean surfaces minimize chemical usage and downtime, supporting eco-conscious operations and lower lifecycle costs.
Plug-and-Play Compatibility
Seamlessly integrates into modular filtration systems, offering scalable solutions for both retrofits and new installations.
